Concentric Hydra™

Enhance Your Homebrewing with the Concentric Hydra™ Wort Chiller

Similar to the original triple feed immersion chiller, the JaDeD Hydra™, this concentric version is constructed of the same amount of copper as the Hydra but in a concentric design, allowing for a lower overall coil profile. The Concentric Hydra™ is perfect for any brewer wanting the speed and efficiency of a Hydra™ but constrained by the level of wort available to cover chilling coils either due to space taken up by a heating element for electric brewing, smaller typical batch sizes or other constraints.

For electric brewing, most brewers combine the Concentric Hydra™ with the ElectriChair™ in order to reap the benefits of this efficient chiller while still protecting the heating element of their setup

This chiller is faster than most plate chillers and will chill a 5 gallon batch from boiling to 68F in just 3 minutes using only 18 gallons of 58F tap water!

Three 25' sections of 3/8" outside diameter copper, working in parallel for a total of 75' of copper coil chilling power.

The design of the Concentric Hydra™ allows you to have the speed of a plate chiller and the ease of sanitation and maintenance of an immersion chiller!

No need for labor intensive backflushing, sanitizing and baking of your plate chiller to limit the possibility of costly brew infections. All you need to do with the Concentric Hydra is put it in the boil for the last 10 minutes and rinse it off after your wort is chilled. No more worrying about hops and cold break clogging things up! There are no hidden extra costs required to reach the specified chilling times, just put the chiller in your pot, crank up the water to full blast and give it a stir. No need to spend an EXTRA $200 to $250 for a food grade pump, fittings and hoses that are needed for a plate chiller to achieve advertised chill times.

Are you concerned about the burn off of your volatile hop oils? The Concentric Hydra™ chills the ENTIRE boil to below 140F in 45 seconds!

The solid brass garden hose fittings are threaded onto soldered 1/2" MPT fittings on the chiller with food safe Teflon tape. The soldered connections avoid common leaking issues typically seen with compression fittings.

Product Details:

• Constructed with 100% food safe materials

• Super fast chill times (5 gallons from boil to 10F above tap water temperature in 3 minutes)

• Fastest of ANY chiller to chill your entire batch to 140F (45 seconds)

• Copper tubing: Three 25' sections of 3/8" outside diameter copper run in parallel

• Easy cleaning procedure

• No need for a food grade pump and hoses to achieve specified chill times

• All solder connections are lead free and potable water safe

• Standard 3/4" solid brass male and female garden hose fittings for chilling water input and output

• Coil specs: 5” high, 12" coil diameter

• Made in the USA

Please feel free to contact us with any questions or comments.

Email us for pricing if you need this chiller customized.
Happy Brewing!

When it comes to homebrewing, having the best equipment can make all the difference. Introducing the Concentric Hydra™ Wort Chiller, an essential tool designed to elevate your brewing experience. This wort chiller is specifically engineered to provide efficient cooling for your wort, ensuring that you achieve the perfect temperature every time. With its superior design and materials, it stands out as a must-have for all serious homebrewers.

The Concentric Hydra™ Wort Chiller is made from high-quality materials to ensure durability and efficiency. Its concentric design allows for maximum contact with the wort, leading to faster cooling times but reducing the risk of contamination. This means that you can start the fermentation process sooner, which is critical in maintaining great taste and quality in your homebrews. The chiller is also easy to use and clean, making it a convenient addition to your homebrewing setup.

Efficiency and performance are the top priorities of the Concentric Hydra™ Wort Chiller. With its advanced cooling technology, it rapidly brings your boiling wort down to yeast-pitching temperatures in mere minutes. This quick cooling is not just about saving time; it’s about preserving the delicate flavors of your brew. Properly chilled wort helps in preventing unwanted off-flavors and bacterial growth, which can ruin batches. The robust tubing and fittings ensure a secure and leak-free operation, giving you peace of mind while brewing.

For homebrewers aiming to produce the highest quality beer, investing in the Concentric Hydra™ Wort Chiller is a step towards better brewing. Its design and functionality are tailored to meet the needs of both novice and experienced brewers, offering unmatched performance and reliability. With rave reviews from the brewing community, this wort chiller is your ticket to consistently excellent homebrews. Don’t compromise on quality; make the smart choice with the Concentric Hydra™ Wort Chiller and enjoy brewing like never before.
